Raimondi Zipper Advanced Rail Saw

The Raimondi Zipper Advanced Wet Saw is high quality machine designed for ripping through porcelain tiles, ceramic, granite, marble, brick, and more.


Features

  • Cast and extruded aluminum framework
  • Rail saw able to plunge cut.
  • Polypropylene pan for easy cleaning capacity 38 lt (10 Gal)
  • Re-adjustable square for long lasting precision
  • Sliding motor assembly with cast aluminum housing provided with adjustable bearings.
  • Floating blade guard system, and child-proof on/off switch with key provides extra safety during saw operation.
  • Material lock-down bar, collapsible table extension and extension side square are optional and sold separately.
  • SPECIAL ORDER - Zipper 150 available by special order from Italy. Takes 4-6 weeks. Call to place order

What's Included?

  • Raimondi Zipper Advanced Rail Saw
  • Folding Telescopic Legs with Wheels
  • 14 in. Segmented Diamond Blade
  • 45°/90° Sliding Square
  • High Volume Water Pump
  • Wrench Kit
  • Operator's manual

Raimondi Zipper Specifications
Model Zipper 85 Zipper 105 Zipper 130 Zipper 150
Power 25 Amp 25 Amp 25 Amp 25 Amp
Voltage 110V 110V 110V 110V
Motor Belt Driven - 2.2 hp Belt Driven - 2.2 hp Belt Driven - 2.2 hp Belt Driven - 2.2 hp
Arbor Size 1 inch 1 inch 1 inch 1 inch
Blade RPM 3360 3360 3360 3360
Blade Size 12 or 14 in 12 or 14 in 12 or 14 in 12 or 14 in
Depth of Cut 4-3/4 in 4-3/4 in 4-3/4 in 4-3/4 in
Length of Cut 34 in 41 in 51 in 61 in
Diagonal Cut 24 in 29 in 35 in 42 in
Weight 176 lbs. 185 lbs. 216 lbs. 233 lbs.
Dimensions 50 in x 27 in x 37 in 57 in x 27 in x 37 in 68 in x 27 in x 37 in 78 in x 27 in x 37 in
Shipping Freight Truck Freight Truck Freight Truck Freight Truck
